Description

Easy and intuitive panel operation
Multi-touch operation similar to smartphone or tablet
Individually adaptable user panel
Direct integration of timesaving solutions
Flexible finishing and media versatility
Comprehensive range of security features
Low energy consumption and outstanding eco performance

Functionality

Copy and print speed of up to 28 ppm A4 and up to 14 ppm A3
Scanning of up to 45 opm
Fax with Super G3 fax option for fast transmission and digital reception, polling, time shift, PC Fax, receipt to confidential box, receipt to e-mail, FTP, SMB
Standard: Embedded controller with 1.2 GHz (SoC architecture)

Media

Standard: 1,100 sheets, max. 3,600 sheets
500-sheet universal cassette (A5-A4, 60-256g/sqm)
500-sheet universal cassette (A5-A3, 60-256g/sqm)
100-sheet bypass (A6-A3, 60-256g/sqm)

Finishing

Inner finisher with 50-sheet multi-position stapling; max. stacking capacity 500 sheets; optional punch kit (2/4 holes)
Floortype finisher with 50-sheet stapling; max. stacking capacity 3,300 sheets in inner tray; optional punch kit (2/4 holes)
Floortype finisher with booklet function and 50-sheet stapling; max. stacking capacity 3,300 sheets in inner tray; optional punch kit (2/4 holes)

Copier Specifications

Copying process	Electrostatic laser copy; indirect
Toner system	High-definition polymerised toner
Copy/print speed A4 mono (cpm)	Up to 28 ppm
Copy/print speed A4 colour (cpm)	Up to 28 ppm
Copy/print speed A3 mono (cpm)	Up to 14 ppm
Copy/print speed A3 colour (cpm)	Up to 14 ppm
Autoduplex speed A4 mono (cpm)	Up to 28 ppm
Autoduplex speed A4 colour (cpm)	Up to 28 ppm
1st Copy/print time mono (sec)	6.8
1st Copy/print time colour (sec)	8.4
Warm-up time (sec)	Approx. 20 (2)
Copy resolution (dpi)	600 x 600
Gradations	256 gradations
Multi-copy	1-9,999
Original format	A5-A3
Magnification	25-400% in 0.1% steps; auto-zooming
Copy functions	Chapter; cover and page insertion; proof copy; adjustment test print; job setting memory; poster mode; image repeat; overlay (optional, with UK-211); stamping; copy protection

Printer Specifications

Print resolution (dpi)	1,800 (equivalent) x 600 dpi
Page description language	PCL 6 (PCL 5c + XL 3.0) PostScript 3 (CPSI 3016) XPS
Operating systems	Windows VISTA (32/64) Windows 7 (32/64) Windows 8 (32/64) Windows 8.1 (32/64) Windows 10 (32/64) Windows Server 2008/2008 R2 (32/64) Windows Server 2012/2012 R2 (64) Macintosh OS X 10.x Citrix Linux
Printer fonts	80 PCL Latin; 137 PostScript 3 Emulation Latin
Print functions	Direct print of PCL; PS; TIFF; XPS; PDF (v1.4); encryptedPDF files and OOXML (DOCX; XLSX; PPTX); mixmedia andmixplex; "Easy Set” job programming; overlay; watermark;copy protection; carbon copy print
Mobile printing	AirPrint (iOS); Mopria (Android); Google Cloud Print (optional); WiFi Direct (optional); Konica Minolta Print Service (Android); PageScope Mobile (iOS, Android); NFC Authentication and Pairing (Android)

Scanner Specifications

Scan speed colour (opm)	Up to 45 ipm
Scan Speed mono (opm)	Up to 45 ipm
Scan resolution (dpi)	Max.: 600 x 600
Scan modes	Scan-to-eMail (Scan-to-Me) Scan-to-SMB (Scan-to-Home) Scan-to-FTP Scan-to-Box Scan-to-USB Scan-to-WebDAV Scan-to-DPWS Network TWAIN scan
File formats	TIFF; PDF; Compact PDF; JPEG; XPS; Compact XPS; DOCX; XLSX; searchable PDF; PDF/A; linerarized PDF
Scan destinations	2,100 (single + group); LDAP support
Scan functions	Annotation (text/time/date) for PDF; up to 400 job programs; Realtime scan preview

System Specifications

System memory standard (MB)	2,048 (standard)
System hard disc standard (GB)	250 (standard)
Interfaces standard	10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0
Network protocols	TCP/IP (FTP; SMB; SMTP; WebDAV) (IPv4/IPv6)
Frame types	Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic document feeder	Up to 100 originals; A6-A3; 35-128 gsm RADF optional avaiable
Paper size	A5-A3; A6S; banner paper; Thick Paper X/Y size inputrange: Width: 90-297 mm; Length: 139.7-431.8 mm
Printable paper weight (g/m²)	60-256 gsm
Paper input capacity (sheets)	Standard: 1,100 sheets Max.: 3,600 sheets
Paper trays standard	Tray 1: 500 sheets; A5-A4; 60-256 gsm Tray 2: 500 sheets; A5-A3; 60-256 gsm Manual Bypass: 100 sheets; A6-A3; 60-256gsm
Paper trays optional	Tray 3: 500 sheets; A5-A3; 60-256 gsm Tray 3 + 4: 2 x 500 sheets; A5-A3; 60-256 gsm Large Capacity Cabinet: 2,500 sheets; A4; 60-256 gsm Manual Bypass: 100 sheets; A6-A3; 60-256 gsm
Automatic duplexing	A5-A3; 60-256 gsm
Finishing modes (optional)	Offset; group; sort; staple; punch; centre-fold; letter fold; booklet
Output capacity (w. finisher)	Max.: 3,300 sheets
Output capacity (w/o finisher)	Max.: 250 sheets
Stapling	Max.: 50 sheets or 48 sheets + 2 cover sheets (up to 209 gsm)
Stapling output capacity	Max. 1,000 sheets
Letter fold	Up to 3 sheets
Letter fold capacity	Max.: 30 sheets (tray); unlimited
Booklet	Max.: 20 sheets or 19 sheets + 1 cover sheet (up to 209 gsm)
Booklet output capacity	Max.: 100 sheets
Copy/print volume recommended (monthly)	13,000 pages
Copy/print volume max. (monthly)	28,000 pages (1)
Toner lifetime Black	24,000
Toner lifetime CMY	21,000
Developer lifetime Black	600,000
Developer lifetime CMY	600,000
Drum lifetime Black	105,000
Drum lifetime CMY	90,000
Power consumption	220-240 V / 50/60 Hz Less than 1.6 kW (system)
System dimensions (WxDxH, mm)	585 x 660 x 735 mm (main body)
System weight (kg)	Approx. 72 kg (without options/toner)

Fax Specifications

Fax standard	G3
Fax transmission	Analogue i-Fax Colour i-Fax IP-Fax
Fax resolution (dpi)	Max.: 600 x 600 dpi (ultra-fine)
Fax compression	MH; MR; MMR; JBIG
Fax modem (Kbps)	Up to 33.6 Kbps
Fax destinations	2,100 (single + group)
Fax functions	Polling; time shift; PC-Fax; receipt to confidential box;Receipt to e-mail/FTP/SMB; up to 400 job programs

User box specification

Max. storable documents	Up to 3,000 documents or 10,000 pages
Type of user boxes	Public Personal (with password or authentication) Group (with authentication)
Type of system boxes	Secure print Encrypted PDF print Fax receipt Fax polling
User box functionality	Reprint; combination Download Sending (e-mail/FTP/SMB and fax) Copy box to box
