Description

Convenient mobile usability
Easy and intuitive panel operation
Multi-touch operation similar to smartphone or tablet
Individually adaptable operating panel
Direct integration of timesaving solutions
Flexible finishing and media versatility
Comprehensive range of security features
Low energy consumption and outstanding eco performance

Functionality

Print and copy speed of up to 30 ppm A4 and up to 15 ppm A3 in colour and black&white
Scanning of up to 160 ipm in colour and black&white
Fax with Super G3 fax option for fast transmission and digital reception, polling, time shift, PC Fax, receipt to confidential box, receipt to e-mail, FTP, SMB
Standard: Embedded controller with 1.2 GH

Media

Standard: 1,150 sheets, max. 6,650 sheets
500-sheet universal cassette (B5 crosswise - A3, 52-256g/sqm)
500-sheet universal cassette (B5 crosswise - SRA3, 52-256g/sqm)
150-sheet bypass (A5 lengthwise - SRA3; width: 90 to 320 mm, length: 139.7 to 1,200 mm, 52-300g/m²) for overhead transparencies, labels, banner paper, thick paper

Finishing

Inner finisher with corner and 2 point stapling, max. capacity 500 sheets
Optional for inner finisher: punch kit (2/4 holes)
50-sheet staple finisher, max. capacity 3,300 sheets + 100 sheets (via inner tray), stapling of max. 50 sheets
Optional for 50-sheet finisher: saddle stitch unit for booklets (centre staple, half fold, tri fold), punch kit (2/4 holes)

Copier Specifications

Copying process	Electrostatic laser copy, tandem, indirect
Toner system	High-definition polymerised toner
Copy/print speed A4 mono (cpm)	30
Copy/print speed A4 colour (cpm)	30
Copy/print speed A3 mono (cpm)	15
Copy/print speed A3 colour (cpm)	15
Autoduplex speed A4 mono (cpm)	30
Autoduplex speed A4 colour (cpm)	30
1st Copy/print time mono (sec)	5.6
1st Copy/print time colour (sec)	7.3
Warm-up time (sec)	Approx. 20 * * Warm up time may vary depending on the operating environment and usage
Copy resolution (dpi)	600 x 600
Gradations	256 gradations
Multi-copy	1-9,999
Original format	A5-A3
Magnification	25-400% in 0.1% steps; auto-zooming
Copy functions	Chapter; cover and page insertion; proof copy (print and screen); adjustment test print; digital art functions; job setting memory; poster mode; image repeat; overlay (optional); stamping; copy protection

Printer Specifications

Print resolution (dpi)	1,800 x 600 1,200 x 1,200
Page description language	PCL 6 (XL 3.0) PCL 5c PostScript 3 (CPSI 3016) XPS
Operating systems	Windows VISTA (32/64) Windows 7 (32/64) Windows 8 (32/64) Windows Server 2008 (32/64) Windows Server 2008 R2 (64) Windows Server 2012 (64) Windows Server 2012 R2 Macintosh OS X 10.x Unix, Linux, Citrix
Printer fonts	80 PCL Latin; 137 PostScript 3 Emulation Latin
Print functions	Direct print of PCL, PS, TIFF, XPS, PDF (v1.7),encrypted PDF files and OOXML (DOCX, XLSX, PPTX);mixmedia and mixplex; "Easy Set” job programming;overlay; watermark; copy protection; carbon copy print
Mobile printing	AirPrint (iOS), Mopria (Android), Google Cloud Print (optional), WiFi Direct (optional), Konica Minolta Print Service (Android), PageScope Mobile (iOS, Android); NFC Authentication and Pairing (Android)

Scanner Specifications

Scan speed colour (opm)	Up to 160 ipm (with optional DF-704)
Scan Speed mono (opm)	Up to 160 ipm (with optional DF-704)
Scan resolution (dpi)	Max.: 600 x 600
Scan modes	Scan-to-eMail (Scan-to-Me) Scan-to-SMB (Scan-to-Home) Scan-to-FTP Scan-to-Box Scan-to-USB Scan-to-WebDAV Scan-to-DPWS Network TWAIN scan
File formats	JPEG; TIFF; PDF; PDF/A 1a and 1b (optional); compact PDF; encrypted PDF; searchable PDF (optional); XPS; compact XPS; PPTX; searchable DOCX/XLSX/PPTX (optional)
Scan destinations	2,100 (single + group); LDAP support
Scan functions	Annotation (text/time/date) for PDF; up to 400 job programs; real-time scan preview

System Specifications

System memory standard (MB)	2,048 (standard)
System hard disc standard (GB)	250 (standard)
Interfaces standard	10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0
Network protocols	TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP
Frame types	Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic document feeder	Up to 100 originals; A6-A3; 35-163 gsm RADF or Dualscan ADF available
Paper size	A6-SRA3, customised paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight (g/m²)	52-300 gsm
Paper input capacity (sheets)	Standard: 1,150 Max.: 6,650 sheets
Paper trays standard	Tray 1: 500 sheets, A5-A3, 52-256 gsm Tray 2: 500 sheets, A5-SRA3, 52-256 gsm Manual Bypass: 150 sheets, A6-SRA3, custom sizes, banner, 60-300 gsm
Paper trays optional	Tray 3: 1x 500 sheets, A5-A3, 52-256 gsm Tray 3 + 4: 2x 500 sheets, A5-A3, 52-256 gsm Large Capacity Cabinet: 2,500 sheets, A4, 52-256 gsm Large Capacity Cabinet (1): 3,000 sheets, A4, 52-256 gsm (LU-302) Manual Bypass: 150 sheets, A6-SRA3, custom sizes, banner, 60-300 gsm
Automatic duplexing	A5-SRA3; 52-256 gsm
Finishing modes (optional)	Offset; group; sort; staple; punch; centre-fold; letter fold; booklet
Output capacity (w. finisher)	Max.: 3,300 sheets
Output capacity (w/o finisher)	Max.: 250 sheets
Stapling	50 sheets or 48 sheets + 2 cover sheets (up to 209 gsm)
Stapling output capacity	Max. 1,000 sheets
Letter fold	Up to 3 sheets
Letter fold capacity	Max.: 30 sheets (tray); unlimited
Booklet	Max.: 20 sheets or 19 sheets + 1 cover sheet (up to 209 gsm)
Booklet output capacity	Max.: 100 sheets (tray); unlimited
Copy/print volume recommended (monthly)	16,000 pages
Copy/print volume max. (monthly)	100,000 pages
Toner lifetime Black	28,000
Toner lifetime CMY	26,000
Developer lifetime Black	600,000
Developer lifetime CMY	600,000
Drum lifetime Black	120,000
Drum lifetime CMY	75,000
Power consumption	220-240 V / 50/60 Hz Less than 1.5 kW (system)
System dimensions (WxDxH, mm)	615 x 685 x 779 mm (excl. ADF and lower paper tray unit)
System weight (kg)	Approx. 85

Fax Specifications

Fax standard	Super G3 (optional)
Fax transmission	Analogue i-Fax Colour i-Fax (RFC3949-C) IP-Fax
Fax resolution (dpi)	Max.: 600 x 600 (ultra-fine)
Fax compression	MH; MR; MMR; JBIG
Fax modem (Kbps)	Up to 33.6 Kbps
Fax destinations	2,100 (single + group)
Fax functions	Polling; time shift; PC-Fax; receipt to confidential box; Receipt to e-mail/FTP/SMB; up to 400 job programs

User box specification

Max. storable documents	Up to 3,000 documents or 10,000 pages
Type of user boxes	Public Personal (with password or authentication) Group (with authentication)
Type of system boxes	Secure print Encrypted PDF print Fax receipt Fax polling
User box functionality	Reprint; combination Download Sending (e-mail/FTP/SMB and Fax) Copy box to box
