Description

Simple and intuitive User Experience
Multi-touch operation similar to smartphone or tablet
Convenient mobile usability
Direct integration of timesaving solutions
High speed scanning with Dual scan document feeder
Automatic paper detection
Flexible finishing and media versatility
Comprehensive range of security features
Antivirus scan engine from Bitdefender®
Low energy consumption and outstanding eco performance

Functionality

Print and copy speed of up to 65 ppm A4 in colour and black&white
Scanning of up to 140 ipm in simplex and 280 ipm in duplex in colour and black&white
Fax with Super G3 fax option for fast transmission and digital reception, polling, time shift, PC Fax, receipt to confidential box, receipt to e-mail, FTP, SMB

Media

Printable paper size: A6–SRA3; customized paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight: 52–300 g/m², automatic paper weight and type detection

Finishing

Corner stapling
Corner stapling (offline)
Two-point stapling
Four-hole punching
Duplex
Combined mixplex/mixmedia
Half-fold
Sheed insertion
Letterfold
Booklet
Offset sorting
Z-fold
Banner printing

Copier Specifications

Imaging technology	Laser
Toner technology	HD polymerised toner
Copy/print speed A4 (mono/colour)	Up to 65/65 ppm
Copy/print speed A3 (mono/colour)	Up to 32/32 ppm
Autoduplex speed A4 (mono/colour)	Up to 65/65 ppm
1st copy out time A4 (mono/colour)	2.8/3.8 sec.
Warm-up time	Approx. 15/17 sec.² ² Warm-up time may vary depending on the operating environment and usage
Copy resolution	600 x 600 dpi
Gradation	256 gradations
Multicopy	1-9,999
Original format	Max. A3
Magnification	25-400% in 0.1% steps; Auto-zooming

Printer Specifications

Print resolution	1,800 (equivalent) x 600 dpi; 1200 x 1200 dpi
Page description language	PCL 6 (XL3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS
Operating systems	Windows 7 (32/64); Windows 8.1 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Windows Server 2019; Macintosh OS X 10.10 or later; Linux
Printer fonts	80 PCL Latin; 137 PostScript 3 Emulation Latin
Mobile printing	AirPrint (iOS); Mopria (Android);optional: Google Cloud Print; WiFi Direct

Scanner Specifications

Scan speed (mono/colour)	Up to 140/140 ipm in simplex Up to 280/280 ipm in duplex
Scan resolution	Up to 600 x 600 dpi
Scan modes	Scan-to-eMail (Scan-to-Me); Scan-to-SMB (Scan-to-Home); Scan-to-FTP; Scan-to-Box; Scan-to-USB; Scan-to-WebDAV; Scan-to-DPWS; Scan-to-URL; TWAIN scan
File formats	JPEG; TIFF; PDF; Compact PDF; Encrypted PDF; XPS; Compact XPS; PPTXoptional: Searchable PDF; PDF/A 1a and 1b; Searchable DOCX/PPTX/XLSX
Scan destinations	2,000 destinations + 100 groups; LDAP support

System Features

Security	Standard:ISO 15408 HCD-PP Common Criteria (in evalutation); IP filtering and port blocking; SSL3 and TLS1.0/1.1/1.2 network communication; IPsec support; IEEE 802.1x support; User authentication; Authentication log; Secure print; Kerberos; Hard drive overwrite; Hard drive data encryption (AES 256); Confidential fax; Print user data encryption optional: Antivirus realtime scanning (Bitdefender®); Copy protection (Copy Guard, Password Copy)
Accounting	Standard: Up to 1,000 user accounts; Active Directory support (user name + password + e-mail + smb folder); User function access definition;Authentication by mobile device (Android) optional:Biometric authentication (finger vein scanner); ID card authentication (ID card reader); Authentication by mobile device (iOS)
Software	store+find (opt.); convert+share (opt.);Device Manager; Box Operator;Data Administrator (user accounts and cost centres); Card solutions (opt.); EveryonePrint (opt.)

Fax Specifications

Fax standard	Super G3 (optional)
Fax transmission	Analogue; i-Fax; Colour i-Fax; IP-Fax
Fax resolution	Up to 600 x 600 dpi
Fax compression	MH; MR; MMR; JBIG
Fax modem	Up to 33.6 Kbps
Fax destinations	2,000 single + 100 groups

System Specifications

Panel size/resolution	10.1” / 1024 x 600
System memory (standard/max)	8,192 MB
System hard drive	256 GB SSD (standard) / 1 TB SSD (optional)
Interface	10/100/1,000-Base-T Ethernet; USB 2.0; Wi-Fi 802.11 b/g/n/ac (optional)
Network protocols	TCP/IP (IPv4 / IPv6); SMB; LPD; IPP; SNMP; HTTP(S); Bonjour
Automatic Document Feeder	Up to 300 originals; A6-A3; 35-210 g/m²; Dualscan ADF
Printable paper size	A6-SRA3; customized paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight	52-300 g/m²
Paper input capacity (standard/max)	1,150 sheets / 6,650 sheets
Paper tray input (standard)	1x 500; A6-A3; custom sizes; 52-256 g/m² 1x 500; A5-SRA3; custom sizes; 52-256 g/m²
Paper tray input (optional)	1x 500 sheets; A5-A3; 52-256 g/m² 2x 500 sheets; A5-A3; 52-256 g/m² 1x 2,500 sheets; A4; 52-256 g/m² 1x 1,500 + 1x 1,000 sheets; A5-A4; 52-256 g/m²
Large capacity tray (optional)	1x 3,000; A4; 52-256 g/m² 1x 2,500; A4-SRA3; custom sizes; 52-256 g/m²
Manual bypass	150 sheets; A6-SRA3; custom sizes; banner; 60-300 g/m²
Automatic duplexing	A6-SRA3; 52-256 g/m²
Finishing modes	Offset; Group; Sort; Staple; Staple (offline); Punch; Half-fold; Letter-fold; Booklet; Post insertion; Z-fold
Output capacity (standard)	Max. 250 sheets
Output capacity (optional)	Max. 3,300 sheets
Stapling	Max. 100 sheets or 98 sheets + 2 cover sheets (up to 300 g/m²)
Stapling output capacity	Max. 200 sets
Letter fold	Max. 3 sheets
Letter fold capacity	Max. 50 sets; unlimited (without tray)
Booklet	Max. 20 sheets or 19 sheets + 1 cover sheet (up to 300 g/m²)
Booklet output capacity	Max. 35 booklets; unlimited (without tray)
Copy/print volume (monthly)	Rec. 53,000 pages; Max.¹ 250,000 pages ¹If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed
Toner lifetime	Black up to 28,000 pages CMY up to 28,000 pages
Imaging unit lifetime	Black up to 240,000/1,000,000 pages (drum/developer) CMY up to 165,000/1,000,000 pages (drum/developer)
Power consumption	220-240 V / 50/60 Hz; Less than 2.00 kW
System dimension (WxDxH)	615 x 688 x 961 mm (without options)
System weight	Approx. 100.0 kg (without options)
