Description

High-speed and high-capacity scanning
Easy and intuitive panel operation
Multi-touch operation similiar to smartphone or tablet
Customisable operation panel
Sophisticated finishing functions
Low energy consumption and outstanding eco performance
High media flexibility and paper capacity
Advanced control for high speed production
Advanced solution connectivity
Convenient mobile usability

Functionality

Copy and Print up to 75 ppm A4 and up to 37 ppm A3 in black & white
Scan up to 240 opm in colour/black & white with up to 300 sheets capacity
Fax with Super G3 fax option for fast transmission and digital reception, polling, time shift, PC Fax, receipt to confidential box, receipt to e-mail, FTP, SMB
Standard: Embedded controller with 1.6 GH

Media

Standard: 3,650 sheets, max. 6,650 sheets
2 x 500-sheet universal cassettes (A5-SRA3, 52-256 g/sqm), 150-sheet bypass (A6-SRA3, 52-300 g/sqm), for standard paper, envelopes, OHP, thick paper
1,000-sheet and 1,500-sheet cassettes (A4, 52-256 g/sqm) for standard paper

Finishing

Booklet finisher for 80-page brochures
Finisher with 50 or 100-sheet stapling, max. 3,200-sheet capacity
Optional for 50-sheet finisher: punch kit (2/4-hole),
Optional for 100-sheet finisher:booklet kit (incl. letter- and center-fold), punch kit (2/4-hole), job separator, post insertion unit, z-fold

Copier Specifications

Copying process	Electrostatic laser copy; tandem; indirect
Toner system	High-definition polymerised toner
Copy/print speed A4 mono (cpm)	Up to 75 ppm
Copy/print speed A3 mono (cpm)	Up to 37 ppm
Autoduplex speed A4 mono (cpm)	Up to 75 ppm
1st Copy/print time mono (sec)	3.6 sec.
Warm-up time (sec)	Approx. 22 sec.¹ ¹ Warm-up time may vary depending on the operating environment and usage
Copy resolution (dpi)	600 x 600 dpi
Gradations	256 gradations
Multi-copy	1-9,999
Original format	A5-A3
Magnification	25-400% in 0.1% steps; auto-zooming
Copy functions	Chapter; cover and page insertion; proof copy (print and screen); adjustment test print; digital art functions; job setting memory; poster mode; image repeat; overlay (optional); stamping; copy protection

Printer Specifications

Print resolution (dpi)	1,800 x 600 dpi 1,200 x 1,200 dpi
Page description language	PCL 6, PCL 5 PostScript 3 (CPSI 3016) XPS
Operating systems	Windows VISTA (32/64) Windows 7 (32/64) Windows 8 (32/64) Windows 10 (32/64) Windows Server 2008 (32/64) Windows Server 2008 R2 Windows Server 2012 Windows Server 2012 R2 Macintosh OS X 10.x Unix; Linux; Citrix
Printer fonts	80 PCL Latin 137 PostScript 3 Emulation Latin
Print functions	Direct print of PCL; PS; TIFF; XPS; PDF (v1.7); encrypted PDF files and OOXML (DOCX, XLSX, PPTX); mixmedia and mixplex; "Easy Set” job programming; overlay; watermark; copy protection; carbon copy print
Mobile printing	AirPrint (iOS); Mopria (Android); Google Cloud Print (optional); WiFi Direct (optional); Konica Minolta Print Service (Android); PageScope Mobile (iOS

Scanner Specifications

Scan speed colour (opm)	Up to 240 ipm
Scan Speed mono (opm)	Up to 240 ipm
Scan resolution (dpi)	Max.: 600 x 600 dpi
Scan modes	Scan-to-eMail (Scan-to-Me) Scan-to-SMB (Scan-to-Home) Scan-to-FTP Scan-to-Box Scan-to-USB Scan-to-WebDAV Scan-to-DPWS Network TWAIN scan
File formats	JPEG; TIFF; PDF; PDF/A 1a and 1b (optional); Compact PDF; encrypted PDF; searchable PDF (optional); XPS; compact XPS; PPTX; searchable DOCX/XLSX (optional); searchable PPTX
Scan destinations	2,100 (single + group); LDAP support
Scan functions	Annotation (text/time/date) for PDF; up to 400 job programs; realtime scan preview

System Specifications

System memory standard (MB)	4,096 MB
System hard disc standard (GB)	250 GB
Interfaces standard	10-Base-T/100-Base-T/1,000-Base-T Ethernet; USB 2.0 Wi-Fi 802.11b/g (optional)
Network protocols	TCP/IP (IPv4 / IPv6); NetBEUI; SMB; LPD; IPP; SNMP; HTTP
Frame types	Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP
Automatic document feeder	Up to 300 originals; A6-A3; 35-210 gsm Dualscan ADF
Paper size	A6-SRA3; customised paper sizes; banner paper max. 1,200 x 297 mm
Printable paper weight (g/m²)	52-300 gsm
Paper input capacity (sheets)	Standard: 3,650 sheets Max.: 6,650 sheets
Paper trays standard	Tray 1: 500 sheets; A5-SRA3; 52-256 gsm Tray 2: 500 sheets; A5-SRA3; 52-256 gsm Tray 3: 1,500 sheets; A4; 52-256 gsm Tray 4: 1,000 sheets; A4; 52-256 gsm Manual Bypass: 150 sheets; A6-SRA3; custom sizes; banner; 52-300 gsm
Paper trays optional	Large Capacity Cabinet (1): 3,000 sheets; A4; 52-256 gsm Large Capacity Cabinet (2): 2,500 sheets; A4-SRA3; 52-256 gsm
Automatic duplexing	A5-SRA3; 52-256 gsm
Finishing modes (optional)	Offset; group; sort; staple; punch; post insertion; z-fold; centre-fold; letter fold; booklet
Output capacity (w. finisher)	Max.: 3,200 sheets
Output capacity (w/o finisher)	Max.: 250 sheets
Stapling	Max.: 100 sheets or 94 sheets + 2 cover sheets (up to 209 gsm)
Stapling output capacity	Max. 1,000 sheets
Letter fold	Up to 3 sheets
Letter fold capacity	30 sheets (tray); unlimited
Booklet	Max.: 20 sheets or 19 sheets + 1 cover sheet (up to 209 gsm)
Booklet output capacity	Max.: 100 sheets (tray); unlimited
Copy/print volume recommended (monthly)	80,000 pages
Copy/print volume max. (monthly)	215,000 pages
Toner lifetime Black	40,800 pages
Imaging Unit lifetime Black	400,000 pages/1,200,000 pages (Drum/Developer)
Power consumption	220-240 V / 50/60 Hz Less than 2.1 kW (system)
System dimensions (WxDxH, mm)	670 x 820 x 1,232 mm
System weight (kg)	Approx. 200 kg

Fax Specifications

Fax standard	Super G3 (optional)
Fax transmission	Analogue i-Fax Colour i-Fax (RFC3949-C) IP-Fax
Fax resolution (dpi)	Max.: 600 x 600 dpi (ultra-fine)
Fax compression	MH; MR; MMR; JBIG
Fax modem (Kbps)	Up to 33.6 Kbps
Fax destinations	2,100 (single + group)
Fax functions	Polling; time shift; PC-Fax; receipt to confidential box; Receipt to e-mail/FTP/SMB; up to 400 job programs

User box specification

Max. storable documents	Up to 3,000 documents or 10,000 pages
Type of user boxes	Public Personal (with password or authentication) Group (with authentication)
Type of system boxes	Secure print Encrypted PDF print Fax receipt Fax polling
User box functionality	Reprint; combination Download Sending (e-mail/FTP/SMB and fax) Copy box to box
